Micro Sandblaster MV-241 Model

Micro Sandblaster MV-241 Model

The SWAM-BLAST® Micro Swam Blasters are designed to introduce a precise amount of finely graded abrasive powder into a controlled stream of compressed air through the abrasive air pathway and out a manually or automatically positioned nozzle tip.



The unique design of Model MV-241 offers “Maximum Versatility”. This model is a combination of the precise ability of the Model MV-2 and the aggressive attitude of the Model MV-2L in one unit. Just press the toggle switch on the front panel to green to use the nozzles from 0.007″ up to 0.040″ or press the toggle switch to amber to use the nozzle from 0.018″ up to 0.060″.



  • Total process control can be achieved with independently adjustable powder flow control and air pressure regulation.
  • Interchangeable orifice plates are available to increase the range of powder types and sizes.
  • Front and back panels unlatch to easily access components and carbide lined fittings throughout the abrasive/air pathway for routine maintenance.
  • The powder tank is mounted to a hinged plate that allows it to tilt to the side and with the push of a button, the vibrator activates to simply walk the powder out for rapid powder changes.



The Crystal Mark team is able to work closely with the customer to select the right SWAM Blaster® for the application.

Item Number #7007-1
Power Requirements: 115VAC, 60Hz, 1amp Weight: 43 pounds (20kg)
Min Air Requirement: 40 psi (276 kPa) Max Air Requirement: 140 psi (965 kPa) maximum
Size: 13″ W x 11″ D x 13″H Shipping Weight: 58 pounds (26.4kg)
Shipping Size: 24″ W x 15″ D 15″ H Other Power: 110V/50Hz, 110V/60Hz & 230V/50/60Hz
