Micro Sandblasters XV-1 Model

Micro Sandblasters XV-1 Model

SWAM-BLAST Model XV-1 Micro Swam Blaster (Xtream™ Volume) is best for operating in production lines and in the SWAM® Automated Systems. The XV-1 features independently adjustable powder flow control and air pressure regulation for total process control, an hour meter for SPC monitoring and a leak detection system for the pinch valve assemblies. It has a separate mixing powder tank for a consistent powder feed rate from a full tank to an empty tank.

The Model XV-1 is similar to LV-1. XV-1 is more suitable for applications that require heaviest output requirements.


For the Model XV-1, the optimum nozzle range is 0.032” up to 0.090”.


Crystal Mark offers additional options for both LV-1 and XV-1 models:


  • Quick Pinch Valve Assembly
  • Low Powder Sensor to detect low levels of abrasive powder within the auxiliary tank
  • Pulse Shaker to enhance the powder flow from the auxiliary tank to the mixing tank
  • Also available are work chambers, dust collectors and air dryers in various configurations to meet the customer’s specific requirements
Item Number #4500-1
Power Requirements: 115VAC, 60Hz, 1amp
Minimum Air Requirement: 40 psi (276 kPa) Maximum Air Requirement: 140 psi (965 kPa)
Standard Cubic Feet per Min: 15 (SCFM) at 140 psi Weight: 76 pounds (34.6 kgs)
Size: 15″ W x 11″ D x 35″ H Shipping Weight: 89 pounds (40.5 kg)
Shipping Size: 20″ W x 17″ D x 40″ H Other Power: 100V/50 Hz, 110V/60Hz, 115V/ 50 Hz & 230V/50/60 Hz
